Application Scenarios
Product Description
The 804 4WD Tractor is a heavy-duty agricultural powerhouse engineered for high-intensity farming and large-scale land management. Featuring a 2050 mm wheelbase and an overall length of 4050 mm, this machine provides exceptional stability and superior traction across diverse terrains. It is driven by a high-performance 4-cylinder engine delivering a robust 80 HP (58.8 kW), ensuring consistent power delivery for demanding professional tasks.
Equipped with a 12F+12R shuttle shift gearbox and a double-stage clutch, the 804 model offers seamless maneuverability and a wide range of operational speeds. The advanced working system includes an external forced lifter and two groups of hydraulic outputs, making it highly compatible with specialized agricultural implements. From the standard open-station design to the optional luxury AC cabin, this tractor is built to provide maximum productivity and operator comfort in any environment.
Key Advantages
High-Capacity Power & Efficiency
-
80 HP 4-cylinder engine provides the high torque necessary for heavy-duty plowing and towing.
-
12 Forward + 12 Reverse gears allow for precise speed matching to optimize fuel efficiency and work quality.
-
Double-stage type clutch enables independent control of the PTO, ensuring efficient operation of rotating attachments.
Heavy-Duty Stability & Traction
-
Long 2050 mm wheelbase prevents pitching and provides a stable platform for heavy rear-mounted implements.
-
Aggressive tire configuration (8.3-24 / 12.4-32) ensures maximum grip and high ground clearance for muddy or uneven fields.
-
4WD system delivers consistent pulling power, allowing the tractor to excel in challenging soil conditions.
Professional Working Capabilities
-
External forced lifter provides strong and reliable lifting force for professional-grade tillage equipment.
-
Dual hydraulic outputs (2 groups) facilitate the operation of complex hydraulic-driven machinery.
-
Dual-speed PTO (540/760 rpm) provides the versatility required to power a wide array of agricultural tools.
Customizable & Operator-Focused
-
Optional AC/Heating Cabin creates a controlled environment for year-round productivity in extreme weather.
-
Flexible configuration options such as air compressors and swing traction allow for tailor-made utility.
-
Multiple engine brand choices (QUANCHAI, LAIDONG, or YANGDONG) provide reliable power solutions tailored to local service needs.
Parameter
| Category | Item | Specification |
| Dimensions | Overall Dimension (LWH) | 4050 × 1820 × 2700 mm |
| Wheelbase | 2050 mm | |
| Engine | Brand | QUANCHAI / LAIDONG / YANGDONG |
| Cylinder Count | 4 | |
| Rated Power | 80 HP / 58.8 kW | |
| Drive Train | Clutch | Double-stage type |
| Gearbox | 12F + 12R | |
| Walking Device | Tire Size (Front/Rear) | 8.3-24 / 12.4-32 |
| Working Device | Tillage Depth Adjustment | External Forced lifter |
| Hydraulic Output | 2 groups | |
| Standard PTO Speed | 6 keys, 540/760 rpm | |
| Optional | Equipment | ROPS, Canopy, AC Cab, Air Compressor, Swing Traction
The 804 4WD Tractor is a heavy-duty agricultural powerhouse engineered for high-intensity farming and large-scale land management. Featuring a 2050 mm wheelbase and an overall length of 4050 mm, this machine provides exceptional stability and superior traction across diverse terrains. It is driven by a high-performance 4-cylinder engine delivering a robust 80 HP (58.8 kW), ensuring consistent power delivery for demanding professional tasks. Equipped with a 12F+12R shuttle shift gearbox and a double-stage clutch, the 804 model offers seamless maneuverability and a wide range of operational speeds. The advanced working system includes an external forced lifter and two groups of hydraulic outputs, making it highly compatible with specialized agricultural implements. From the standard open-station design to the optional luxury AC cabin, this tractor is built to provide maximum productivity and operator comfort in any environment. |
